OASE ProfiClear Premium XL Gravity Drainage Module
Available immediately, delivery time: 3-6 Werktage**
The drainage module for the Oase gravity drum filter in enlarged form.
The enlarged drainage module for the Oase gravity drum filter.
With sufficient space for easy integration of AquaMax Eco Expert and AquaMax Eco Titanium filter pumps as well as the new Bitron Premium UVC pre-clarifiers.
Maximum flexibility in connection thanks to 5 x DN-110 outlets and 4 x Tradux (2" feed-throughs).
An integrated drain at the bottom, including a slide valve, is used to dispose of settled dirt.
Made in Germany – 2-year warranty (+1 year after registration)
Monday to Friday: 9 a.m. to 5 p.m.
| Dimensions (L x W x H) | mm | 1330 x 875 x 820 |
|---|---|---|
| Net weight | kg | 101.60 |
| Warranty (+ extended warranty) | years | 2 + 1 |
| Biological filter surface area | m | 400.0 |
| Protected biological filter surface area | m | 81.0 |
| Material | GRP thermoset/stainless steel | |
| Number of inlets | ST | 2 |
| Input connections | mm | 180 |
| Number of outputs | ST | 9 |
| Output connections | 4 x 2" / 5 x DN 110 | |
| Connections for dirt outlet | DN 75 | |
| Litres per hour min. | l/h | 25,000 |
| Litres per hour max. | l/h | 66000 |
| Connection to | Bitron Premium, ProfiClear Premium TF-XL Gravitation OC, ProfiClear Premium XL Moving Bed | |
| Installation height above water level | cm | 8.5 |
| Type of use | Gravity | |
| Other | – |
