Inazuma Biochamber Katana
Available immediately, delivery time: 1-3 days**
Stainless steel biochamber with over 300 l (gravity feed) or 200 l (pump feed) usable bio volume. Suitable for filters in the Quantum series, katan series and drum filters in the septem series "without biochamber".
- Description
- Instructions for use
- Important information
- Technical specifications
- Information on product safety
Stainless steel biochamber with over 300 l (gravity feed) or 200 l (pump feed) usable bio volume. Suitable for filters in the Quantum series, katan series and drum filters in the septem series "without biochamber".
The bio chamber can be combined with the following filters:
Quantum 60 + 1 bio chamber
Quantum 90
+ 2 bio chambers
Quantum 120
+ 3 bio chambers Biological
purification with the filter media ensures that pollutants in the water are broken down and your fish remain healthy. Algae can also be effectively combated with an optionally available UV-C lamp. A connection for an air hose to aerate the biology is included.
Many plastic filters available on the market no longer work properly after just a few years, as the changing seasons and different temperatures take their toll. What was once considered a bargain purchase turns out to be a total financial loss.
Not so with Inazuma – the solid construction and the use of corrosion-resistant, industrial-grade V4A (1.4571) stainless steel make the Inazuma bio chamber a reliable worker in your garden pond for many years – a real alternative to the plastic filters available on the market.
The filter can be used for pump operation as well as for gravity-fed installation.
The removable cover allows easy access to the filter interior, while the V4A stainless steel body guarantees long-lasting quality.
The guaranteed supply of spare parts directly from the manufacturer ensures many years of enjoyment with a solid, low-maintenance filter made in Germany.
The filter housings are made of specially passivated V4A stainless steel.
In addition to a 2-year manufacturer's warranty including on-site service throughout the UK, you have the option of purchasing an optional warranty extension for a further 2 years. All in all, you can get at least a "4-year all-round carefree package" together with the drum filter. Quality – made in Germany.
*The new warranty applies to all filter models in the "katan" series
. We do not offer a loyalty bonus or fish voucher for this item.
Monday to Friday: 9 a.m. to 5 p.m.
Pump/gravity version
1 - Pond pump
2 - Bottom drain with filter
3 - Skimmer
4 - Pump chamber (gravity)
5 - T-piece open at the top for venting the return line
6 - Return to the pond (cleaned water)
7 - Dirt drain (drainage channel, drainage shaft, hedge)
Pump version
1 - Pond pump
2 - Connection between pond pump and
filter 3 - Return to pond (cleaned water)
4 - T-piece open at the top for venting the return pipe
5 - Dirt drain (sewer, drainage shaft, hedge)
Due to the tight margins on these items, we are unable to offer a loyalty bonus. However, the sales amount will be credited to your account, so you will receive the increased loyalty bonus on all other items.
This item is delivered on a pallet (by freight forwarder).
| Koi ponds up to: | 120 m³ |
| Garden ponds up to: | 200 m³ |
| Installation type: | Gravity/pumped |
| Max. flow rate gravity: | 55 m³/h |
| Max. flow rate pumped: | 40 m³/h |
| Weight: | approx. 50 kg |
| Integrated biochamber: | Yes |
| Usable bio volume: | approx. 300 l gravity/200 l pumped |
| Usable quantity of Hel-X® 17 KLL: | approx. 200 l |
| Degradable feed per day: | approx. 500 g |
| Returns (DN 100): | 5 |
| Inflows (DN100): | 5 |
| Dimensions (LxWxH) | 770 x 890 x 680 mm |
